This LED Light Technology linear fixture is a cost-effective versatile fixture that offers incredible energy savings utilizing motion sensor microwave technology. With emergency back-up, motion sensing and dimmability capabilities this fixture will ensure huge energy savings and reliability with no maintenance for many years!
The LED+ High Bay is designed for industrial or commercial applications where reliability and performance are important. The long LED life of this fixture virtually eliminates maintenance for 150,000 hours. Every component of the LED+ High Bay has been carefully engineered to provide reliable performance and bring across many benefits of utilizing solid state lighting technology in industrial applications.
The CLE fixture family offers unparalleled performance and reliability across a broad range of applications. With an industry-leading efficacy of 160 lm/W, CLEs offer a cost-effective alternative to uncontrolled LED, fluorescent, and HID high bay fixtures. Available in a variety of lumen output, optic, and color temperature options, the CLE’s innovative design is particularly well-suited for ambient warehousing and complex, lean manufacturing environments where Digital Lumens’ progressive dimming feature, fast, facility-wide reprogramming capabilities, and detailed reporting generate significant energy savings and new efficiencies.
Wirelessly Networked for Comprehensive Reporting & Easy Management
When connected to LightRules® lighting control and business intelligence platform, CLEs collect a multitude of operational data and unlock unprecedented insight through detailed reporting to deliver optimized energy and cost savings. With LightRules controls and facility-wide reprogramming capabilities, CLEs support comprehensive lighting strategies, such as progressive dimming and daylight harvesting, to enhance employee comfort and safety while increasing overall efficiency.
Integrated Sensing & Intelligence
All CLE high bay fixtures feature integrated power metering, occupancy and daylight sensors, and three optic options to deliver high-quality light and maximum efficiency, flexibility, and control.
Ultra High Efficacy
The CLE family delivers industry-leading efficiency of 160 lm/w. Standardized12,000, 18,000 and 24,000-lumen output versions are available for quick and easy direct retrofit of 150 W, 250 W and 400 W metal halide fixtures.
Rigid Steel Chassis
The streamlined steel chassis delivers value without compromising durability.
Aisle, Wide & Diffuse Optic Options
Three optic options deliver high-quality light and maximum efficiency, flexibility and control across a variety of workspaces.
Specification Highlights:
Lumen Output:12,000 lm, 18,000 lm, 24,000 lm
IP Rating:IP20
Color Temperature:5,000 Kelvin or 4,000 Kelvin CCT
CRI:80 minimum, 82 typical
Efficacy:151-160 lm/W
Power Supply:78-148 W @ 277 VAC
Optics:Wide, Aisle, Diffuse
Certification:UL/cUL, UL-NOM, CE, FCC Part 15 Class B
Warranty:5-Year Limited, 10-Year Limited (Optional)
Click below for Product Specification Sheet
For Maximum Savings
Among the award-winning portfolio of Intelligent LED fixtures from Digital Lumens, the DLE fixture family offers unparalleled performance and reliability to a broad range of commercial, industrial, and sporting applications. With market-leading value and efficiency, DLEs are high-performance alternatives for uncontrolled LED, fluorescent, and HID high bay fixtures.
Available in four output options, DLEs feature integrated occupancy and daylight sensors, power metering, rotatable light bars, and several optics options to maximize efficiency, flexibility, and control. With adjustable direct/indirect lighting, DLEs are ideal in applications that require lighting uniformity and distribution across both ceilings and workspaces.
DLEs are wirelessly networked to LightRules®, the lighting and energy management software from Digital Lumens, unlocking unprecedented business insight through detailed, intuitive reports. In addition, LightRules Automated Life-Safety testing and reporting and the Battery Backup hardware for DLE fixtures provide code-compliant emergency lighting.
Integrated occupancy and daylight light sensors
Software-defined coordinated control and progressive dimming to maximize visual comfort and energy savings
Narrow, wide, aisle, and diffuse optic options to accommodate a broad range of applications
Independently rotatable light bars for best light placement
Uplighting with thousands of direct/indirect distribution options
Automated Life-Safety testing and code-compliant emergency lighting option with Battery Backup
Power supply alternatives
Proven reliability through a rugged industrial design
Specification Highlights:
Lumen Output:12,000 lm, 18,000 lm, 24,000 lm, 48,000 lm
IP Rating:IP52
Color Temperature:4,000 K, 5,000 K CCT
CRI:70 minimum, 72 typical
Efficacy:120 lm/W (for 5,000 Kelvin fixtures)
Power Supply:100-277 V AC, 347-480 V AC
Optics:Narrow, Wide, Aisle, Diffuse
Certification:DLC Premium, UL, cUL, UL-NOM, CE, C-Tick and more
Warranty:10 years on complete fixture
Click below for Product Specification Sheet
Translations
Ideal for a broad range of facilities, ILE™ fixtures feature an exceptional temperature range and a watertight IP65 rating. ILEs are one-for-one replacements for traditional HID and fluorescent high bay fixtures and feature:
Unparalleled energy efficiency, reducing lighting energy use by up to 90%
Maximum flexibility with independently rotatable light bars for best light placement
Total controllability – built-in occupancy and ambient light sensing, configured wirelessly with the LightRules management system, delivering the right amount of light precisely where and when needed
Multiple optics options to address each facility’s unique needs
Power supply alternatives
Proven reliability through a rugged industrial design
Click below for Product Specification Sheet
Designed for locations requiring Class I Div 2, Class II Div 2, and Class III fixtures, HLE fixtures bring Digital Lumens’ intelligence, efficiency, and performance to facilities with additional safety concerns. With no ongoing maintenance, long lifetimes ratings, and the ability to fine-tune lighting settings remotely, intelligent LEDs are particularly advantageous in these locations.
One-for-one replacements for traditional HID and fluorescent high bay fixtures, HLEs feature:
Unparalleled energy efficiency, reducing lighting energy use by up to 90%
Maximum flexibility with independently rotatable light bars for best light placement
Total controllability – built-in occupancy and ambient light sensing, configured wirelessly with the LightRules management system, delivering the right amount of light precisely where and when needed
Multiple optics options to address each facility’s unique needs
Proven reliability through a rugged industrial design
Specification Highlights
Lumen Output:13,000 lm, 18,000 lm, 26,000 lm
IP Rating:IP65
Color Temperature:5,000K CCT
CRI:70 minimum, 72 typical
Efficacy:102 lm/W
Power Supply:208-277 V
Optics:Narrow, Wide, Aisle
Certification:DLC Qualified, UL, & NOM
Warranty:10 years on complete fixture
Click here for Product Specification Sheet
Translations
For a broad range of low to mid bay environments, Digital Lumens intelligent LLE fixture family includes highly versatile, controllable, and efficient linear LED fixtures. LLEs are replacements for 1L and 2L T5/T8/T12 fluorescent lighting.
Wirelessly Networked for
Comprehensive Reporting & Easy Management
When connected to LightRules®, the lighting control and business intelligence platform from Digital Lumens, LLEs collect a multitude of operational data and unlock unprecedented insight through detailed reporting to deliver optimized energy and cost savings. With software-based controls and facility-wide reprogramming capabilities, LLEs support advanced lighting strategies — such as progressive dimming, coordinated control, and daylight harvesting — to enhance occupant comfort and safety while maximizing efficiency.
LLE Highlights:
Mounting flexibility — ability to install standalone fixtures or end-to-end
Control flexibility for individual fixtures or group management
Diffuse optic eliminates point sources and glare
Control flexibility for individual fixture or group management
Digital Lumens’ signature intelligence – occupancy and ambient light sensing, comprehensive reporting – configured and controlled wirelessly with LightRules®
No maintenance or re-lamping
No glass or mercury
Reported TM-21 lifetime of 60,000 hours (120,000+ hours calculated)
Specifications:
Length:4 ft. (1.2 m)
Lumen Outputs:4,000 lm, 6,500 lm (nominal)
IP Rating:IP40
Color Temperatures:4,000 K, 5,000 K CCT
CRI:80 minimum, 82 typical
Efficacy:125 lm/W
Power Supply:120-277 V
Optics:Diffuse
Certification:DLC Premium Qualified, UL, cUL, UL-NOM, CE
Warranty:10 years on complete fixture
Click here for Product Specification Sheet
Translations
The LED Light Technology 150W and 200W LED High Bays deliver unmatched long-lasting performance from glare prevention, superior light quality, and brilliant prismatic lens. Fitted in a distinct low profile and clean finish, this LED High Bay is a one-for-one replacement. This fixture is ideal for use in warehouse facilities.
Click Below for Product Specification Sheet
Replace 150 to 1500 HID fixtures with LED Light Technology's DLC listed High Bay fixture. High performance LED light engines with Cree XT-E LED deliver more than 100 lumen per watt.
